Type:YF-S201C
Interface size:4 points (G 1 / 2)
Working voltage range:DC5~ 15V
Water pressure resistance:1.75MPa
Output pulse high level:> DC 4.7V (input voltage DC 5V)
Output pulse low level:< DC0.5V (input voltage DC5V)
Insulation resistance:> 1 00MQ
Precision:(in 1 ~ 30L\ MIN) 10%
Sealing property:Close the holes and add 1.7Mpa water pressure test for 1 minute.No leakage and deformation
Flow pulse characteristics:F =(7.0 ≤ Q) error ≤ 3%
