PARAMETER:
Shape dimension long x wide x 48 29 22 mm thickness measurement range DC0-100 V
The size of holes and x27mm minimum input DC0V
Lead length 15 cm highest DC120V input
Net weight 18 g allow error 1% (+ /-a word)
Wool heavy 25 g (including packaging) showing the way three 0.56 "LED digital tube
Display color red green blue can be chosen
Moving speed of about 500 mS/time
The power supply DC4.5-28 V
Current consumption less than 20 mA, general 5-15 mA
Working temperature-10 ℃ ~ 65 ℃
