Kiváló ajándéknak is, már tapasztaltabb elektronikásoknak, akik még kezdők az SMD alkatrészekkel.
Gyakorolható a különböző méretű alkatrészek forrasztása, egészen a kézzel még legkisebben forrasztható 0603-astól a kényelmes 1206-os alkatrészekig, sőt még 0402-vel is megpróbálkozhatnak az ügyesebbek, emellett SOP, SOT, SOIC, QFP alkatrészek felforrasztására van lehetőség. A PCB panel egy jó referencia is, vonalzót, vezetősáv vastaság mintát tartalmaz 6-100mil méretekben.
A KIT tartalmazza a panelt, és az SMD alkatrészeket is!
Kínálatunkban rengeteg forrasztási segédanyagot is találhat (páka, hőlégfúvó, rézharisnya, ónszippantó, ónok, stb)
1. Board size: 90*60MM
2. Thickness of the board: 1.6mm
3. Board material: international standard plate, all pads are tinned, high-strength fireproof and anti-drop material, can be disassembled repeatedly.
4. The PCB board design is reasonable, and the commonly used chip components are used.
5. The three columns of left and right components are used to practice welding, and each column has a test point.
6. The circular circuit in the middle is a water lamp circuit, which is composed of CD4017, NE555, and light-emitting diodes. It can work after power-on after welding without error.
7. The back of the circuit is also used, with a ruler, which is convenient for measuring components. There are examples of PCB wires to facilitate PCB design and use.
8. Circuit working voltage 3~12V
9. This kit contains all the components in the following photos.
About this item
- DIY SMD components can stimulate children's interest and talents in learning,it will make them love electronics projects.
- The solder learning kit has proper circuit design with led indicator, easy to check your soldering result, them will be a flashing LED light after soldered and powered with 3-12V, very interesting effect.
- The left and right 3 columns of components are used for practicing welding
- The middle of the circular circuit for the water lamp circuit, by the CD4017, NE555, light-emitting diodes, welding power can work.
- The back of the PCB board is marked with mm/in scale for easy measurement of components, and also marked with PCB line width example, can be used as a design PCB reference. It's DIY Kits, Red Led
- Please make sure all components in right direction and right place; and check whether pseudo and float welding, this is very important in practicing and testing.
1.Board Size:89*58mm
2.Board Thickness:1.6mm
3.Flow Water Lamp Circuit : CD4017,NE555,LED;after correct connnection,it will operate
4.Operating Voltage :3-12V
5.board material: international standard sheet, all tin pad, high strength fire drop material, can be repeated disassembly.
6. PCB board design is reasonable, are commonly used in the SMD components.
7. the left and right of the three components are used to practice welding, each column with a test point.
8. the middle of the circular circuit for the water lamp circuit, by the CD4017, NE555, light-emitting diodes, welding power can work.
9. the circuit is also used on the back, a ruler to facilitate the measurement of components.There are examples of PCB conductors to facilitate the use of PCB design.
